Aluminium Aerial Platform （Dual mast）
aluminum aerial platform/ hydraulic lift/ aluminum lifting platform/ aluminum platform lift / aluminum lift table double mast/ aluminum alloy lift platform/ GTWY
Applicable Industries: Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company
Categories: Aluminum Lift Platform, Aerial Work Platform
Description
Aluminium Aerial Platform （Dual mast） | |||
| Model Number | AWP6-2000 AWP8-2000 AWP10-2000 AWP12-2000 | ||
| Rated Capacity kg | 300 300 250 200 | ||
| Max. Platform Height mm | 6000 8000 10000 12000 | ||
| Max. Working Height mm | 7700 9700 11700 13700 | ||
| Ground Clearance mm | 80 80 80 80 | ||
| Platform Size mm | 1500*600 1500*600 1620*600 1740*600 | ||
| Outspread Size mm | 1950*1850 1950*1850 2130*1980 2550*2500 | ||
| Electrical Source | AC v | 220 | |
| DC v | 24 | ||
| Battery v/Ah | 2*12/60 | ||
| Charger v/Ah | 24/10 | ||
| Lifting Motor | AC v/kw | 220/1.5 | |
| DC v/kw | 24/2.2 | ||
| Overall Length mm | 1550 1550 1670 1790 | ||
| Overall Width mm | 900 | ||
| Overall Height mm | 1970 1970 2070 2070 | ||
| Overall Net Weight | AC kg | 480 580 680 780 | |
| DC kg | 510 610 710 810 | ||
Warranty:1year
Packaging Details:
FAQ
- Do you accept customized design?Do you offer OEM & ODM service?
Yes,of course!We have over 10 years’ experience in customized design product,expecially lift table.
- What information should I provide for a customized order?
The more information you provide, the accurate solution we can prepare for you.Such as: control by manual or electric, stationary or mobile, power source/voltage demand, load capacity, lifting height(min.height and max height), table size and other information required.
- What is your MOQ?
One unit.The more the better.The price is negotiable for large quantity.
- What is your payment term?
For stock items,T/T in advance.
For customize order,30% T/T in advance,balance before shipping.
- What is the delivery time?
For stock items,send out in 1-3 workdays after payment.
For customized order, we can deliver in 15-25 days. It’s based on what’s kinds of styles and the quantity.
- How long is the warranty time?
One year or 2000 hours,whatever come first.
- How can I get the after-sales service?
Usually on line and video if necessary.Lifetime technical support.
- How do you do to control quality?
We comply with IS09001 standards strictly and most of our products are CE approved.
